AC Drive
AC Drive A200 Series Mini Sensorless Vector Inverter
-
A200 mini economic inverter is positioned as a common application of small power OEM matching market, adopting vector V / F control technology. This series of inverters have many common functions, such as PID, multi-stage speed, DC braking, MODBUS communication, etc., with complete functions and sma
- 产品介绍
- 产品参数
- 产品选型
- 安装尺寸
- 资料下载
| AC Drive Model | Power Capacity (KVA) | Rated Input Current (A) | Rated Output Current (A) | Adapted Motor(KW) |
| Input Voltage(single-phase): 200～240V 50/60Hz | ||||
| T200-2S0.4 | 1 | 5.4 | 2.3 | 0.4 |
| T200-2S0.75 | 1.5 | 8.2 | 4 | 0.75 |
| T200-2S1.5 | 3 | 14 | 7 | 1.5 |
| Input Voltage (three-phase): 380～480V 50/60Hz | ||||
| T200-4T0.75 | 1.5/3 | 3.4/5 | 2.1/3.8 | 0.75/1.5 |
| T200-4T1.5 | 3/4 | 5/5.8 | 3.8/5.1 | 1.5/2.2 |
| T200-4T2.2 | 4/4.9 | 5.8/8.0 | 5.1/6.8 | 2.2/3.0 |
| Shell Code | Model | Installation Size(mm) | Outline Dimension(mm) | Diameter (mm) | GW (kg) | ||||
| A | B | H | H1 | W | D | ||||
| M1 | T200-2S0.4B | 56 | 130 | 142 | 145.5 | 68 | 131 | 5.0 | 0.8 |
| T200-2S0.75B | |||||||||
| T200-2S1.5B | |||||||||
| T200-4T0.75 | |||||||||
| T200-4T1.5 | |||||||||
| T200-4T2.2 | |||||||||
